ENERGY INDEPENDENCE,
COST SAVINGS

ENERGY STORAGE

ENERGYCLOUD

more info

HOW IT WORKS HOME BATTERY

EnergyCloud Home Batteries store solar energy generated during the day that can be used at any time. Alternatively, the Home Batteries can be charged during low-priced periods when demand for electricity is low and be discharged during more expensive high demand periods.

Sun Solar Panel Battery Storage Electric Car

I am interested in detailed info about EneryCloud batteries.

    ( + ) How does EnergyCloud Home Battery work?

    1 Rooftop PV solar system generates free energy for your household. 2 EnergyCloud Home Batteries store your surplus energy during daylight hours rather than exporting it to the grid. Home appliances always draw their own energy from the sun first. 3 In case that PV solar system is not generating enough electricity (the sun is not shining) Energy Cloud Home Battery allows you to use stored energy or draw it from the grid. 4 Households with electric cars will also benefit by being able to charge their cars with a quick charger included (optional) in EnergyCloud Home Battery.
    Energy from the sun Energy storage Non-disrupted service
    ( + )

    SOLUTION DESCRIPTION BATTERY PARAMETERS

    By using EnergyCloud Home Battery solution you can increase your energy independence and derease electricity cost while using cleaner energy.

    Wiring: Single phase output

    Storage capacity: 7.6 kWh

    Guaranteed battery life: 10 000 cycles

    Power and overload ability: 1 x 3.6 kW (1 x 5.4 kW)

    Charging cycle: Fully automatic, usually 2-3 hours

    Model: All-metal dust proof panel

    Product dimension: 0,8 x 1,3 x 0,3 m

    Total Weight: 380 kg

    Colour, design: Supply Mode

    Battery Chemistry: LiFePO4

    ---

    Wiring: Single phase output

    Storage capacity: 15.2 kWh

    Guaranteed battery life: 10 000 cycles, Lifetime warranty

    Power and overload ability: 1 x 3.6 kW (1 x 5.4 kW)

    Charging cycle: Fully automatic, usually 2-4 hours

    Model: All-metal dust proof panel

    Product dimension: 0,8 x 1,9 x 0,3 m

    Total Weight: 380 kg

    Colour, design: Supply Mode

    Battery Chemistry: LiFePO4

    ---

    Wiring: Three phase output

    Storage capacity: 22,8 kWh

    Guaranteed battery life: 10 000 cycles, Lifetime warranty

    Power and overload ability: 1 x 10.0 kW (1 x 15.0 kW)

    Charging cycle: Fully automatic, usually 3-5 hours

    Model: All-metal dust proof panel

    Product dimension: 1,6 x 1,3 x 0,3 m

    Total Weight: 520 kg

    Colour, design: Supply Mode

    Battery Chemistry: LiFePO4

    ---

    Wiring: Three phase output

    Storage capacity: 30,0 kWh

    Guaranteed battery life: 10 000 cycles, Lifetime warranty

    Power and overload ability: 1 x 10.0 kW (1 x 15.0 kW)

    Charging cycle: Fully automatic, usually 4-6 hours

    Max Charger Power: 30 kW DC

    Model: All-metal dust proof panel

    Product dimension: 1,6 x 1,9 x 0,3 m

    Total Weight: 710 kg

    Colour, design: Supply Mode

    Battery Chemistry: LiFePO4

    ---

    Wiring: Three phase output

    Storage capacity: 38,0 kWh

    Guaranteed battery life: 10 000 cycles, Lifetime warranty

    Power and overload ability: 1 x 10.0 kW (1 x 15.0 kW)

    Charging cycle: Fully automatic, usually 4-6 hours

    Model: All-metal dust proof panel

    Product dimension: 1,6 x 1,9 x 0,3 m

    Total Weight: 800 kg

    Colour, design: Supply Mode

    Battery Chemistry: LiFePO4

    ---

    ( + ) Check energy from anywhere

    You can view your home energy consumption online on your phone or see a detailed analysis on a computer. Home Battery control unit monitors the processes and automatically adjusts them accordinging to specified rules. These rules can be customized based on parameters such as power requirement, consumption schedule and current electricity prices.
